Indented Cylinder

Indented Cylinder
Indented Cylinder
Product Code : 02
Product Description

The Agriculture Processing Machine Indented Cylinder offered by us are quite popular in the market for its sturdy construction, superior finishing, unbeatable efficiency and impeccable quality. These cylinders are made from quality raw material, and are fitted with worm conveyor & indented sheets to push cut grains out of the machine. The cylinders can be made available in diverse specifications to meet varied requirements of the customers.

AGRICULTURE PROCESSING MACHINE INDENTED CYLINDER TR-620 / -625 / -630 / -725 / -730 / -930

The TR indented cylinder is developed to be a part of modular system, which means that the number of indented cylinders depends on the capacity and plant layout requirements.

A plant's existing capacity can be increased at any point of time by just adding 1 or more cylinders to it.

The estimated capacity on wheat is upto 12 t/h for TR-930, 10 t/h for TR-730, 7.5 t/h for TR-725, 7 t/h for TR-630, 6 t/h for TR-625, and 5 t/h for TR-620.

Features:

The cylinder in TR machine (standard design) can be fixed with agitator / agitator with auger / outlet brake.

The exchangeable mantle is 2 parted with the following dimensions:

  • 900 x 2910 mm for TR-930

  • 700 x 2910 mm for TR-730

  • 700 x 2410 mm for TR-725

  • 600 x 2910 mm for TR-630

  • 600 x 2410 mm for TR-625

  • 600 x 1910 mm for TR-620

The position of the Trough can be adjusted infinitely.

There are safety access doors on right and left side of the mantle in this machine.

Also, there is a fixed speed drive & 3.0/ 2.2/ 1.5 /1.1 kW motor, 900 rpm, depending on the model.

The machine has robust steel construction.
