Transformer Oil Filtration Machine

Transformer Oil Filtration Machine
Transformer Oil Filtration Machine
Product Code : 09
Product Description

Highly acclaimed in providing the optimum quality Transformer Oil Filtration Machine, we are providing these at competitive prices. Well known for their impeccable performance, easy installation and sturdy structure, these machines are widely used in chemical and oil industries for filtering different impurities such as solid impurities, dissolved water, dissolved gases from the oil. Endowed with most efficient degassing system, these machines have minimal maintenance. Equipped with condensers and audio / visual annunciation, these are highly functional. Having most efficient degassing system, these Transformer Oil Filtration Machines have compact designs and sturdy structures. One of the exclusive things these products have is their easy and replaceable non-hygroscopic filter cartridges. These products are also proved in drying out the moisture inside winding and cellulose insulation.

Features:

  • Low watt density heater, vacuum dehydration and degasification

  • Optical fluid level control system, fuse-less control panels

  • Interlocked preventive mechanism

  • Weatherproof enclosures.

Oil Conditioning Machines Technical Parameters

Description Models

JMHV

JHV

JHVR

Vacuum Level at Final Oil Run Through (in torr)

<3

< 1

< 0.5

Unprocessed Oil Quality

Water content (Max.) ppm

50

50

50

Gas content (Max.) % vol.

10

10

10

Break down voltage kV

20

20

20

Oil Quality After Single Pass

Water content (Max.) ppm

20

6

3

Gas content (Max.) % vol.

2

0.5

0.1

Break down voltage kV

50

60

65

Oil Quality After Two Passes

Water content (Max.) ppm

10

3

2

Gas content (Max.) % vol.

1

0.1

0.05

Break down voltage kV

60

70

7
